Reverse Engineering, Legacy Engineering, & Product Verification

Today’s tooling and manufacturing processes require digital data to create, re-create, document, and duplicate products, machines, prototypes, or legacy products.

Reverse engineering is a multi-step process of creating 3D CAD data from existing products. This is typically a legacy project that does not have the necessary digital CAD data needed to reproduce or change an existing product. This process is often used for clients that have old products that need to be re-tooled, or who acquired physical product lines or equipment without the needed 3D CAD data. Even when a product is developed from a physical model such as clay, wood, or similar techniques, Reverse Engineering can be utilized to document and tool the existing part.

Broadview will create the 3D CAD data for YOUR project through a variety of methods such as scanning, CMM, metrology, measurements, or from any 2D data or existing legacy drawings.





Reverse Engineering

Scan

Scan

Cad Creation

Cad Creation

Prototype

Prototype

Production

Production




Scanning

  • Laser Scanning

  • White Light / Blue Light Scanning

  • CT Scanning

Metrology

  • Coordinate Measurement Machine (CMM)

Measurements

  • Manual calipers, mics, tapes, templates, etc.

2D to 3D Conversion

  • Old or legacy drawings can be used to create 3D CAD models.

3D CAD Creation

  • Broadview creates the 3D CAD data that YOUR project requires based on your needs and goals.

  • Point Cloud Data - raw scan data, typically not enough to complete your goals.

  • STL surface files - sufficient for 3D-printing

  • Parametric Models - typical for tooling, CAM, CNC requirements

  • Advanced surfacing - needed for complex organic shapes that need to be duplicated in high tolerance and appearance tooling.





Engineering to Bring Your Products into the Digital World

  • Engineering Drawings for Tooling, Production, Sales Support

  • Laser Scanning and Conversion to CAD

  • CMM Metrology and Creation of CAD

  • Compare measured data to your existing CAD model to ensure dimensional accuracy





CAD model creation in

  • Solidworks

  • Creo(Pro/E)

  • Autodesk Inventor,

  • Fusion360,

  • AutoCAD

Engineering cad model creation.jpg




Providing Solutions

Broadview Product Development can assist you with your products and projects to verify dimensions or prepare to retool an existing product. Perhaps you acquired a new product line without the original drawings or data, or you need to make changes to product but you don’t have the original data. We can help.

Legacy Engineering and Product Verification.jpg




Why People Choose Broadview

YEARS OF EXPERiENCE


For over 30 years clients like you have trusted Broadview with projects large and small, from corporate projects to individual inventors, concept development or product launch through production.

Under one roof


3D Printing, CNC, Urethane Casting, Show ready Models, welding & fabrication, Finishing and complete functional assemblies, in the same building as our Engineers and Designers. Collaboration is a cornerstone of our success.

Solutions


Creating the solutions YOU need through working with you, your team, and your suppliers.
